DQ-309H Digital Transmitter – Multi-Channel Industrial Weighing & Force Measurement

DQ-309H Digital Transmitter – Multi-Channel Industrial Weighing & Force Measurement

Product Description:

The DQ-309H is a DIN35mm rail-mountable digital transmitter designed for multi-channel industrial force measurement and weighing applications. It supports up to 6 independent ADC channels and is compatible with analog resistive strain gauge sensors (sensitivity output: -3mV/V to 3mV/V). Equipped with high-speed Ethernet data transmission, MODBUS-RTU and MODBUS-TCP protocols, and simultaneous RS232/RS485 communication, the DQ-309H delivers reliable, interference-resistant performance in demanding industrial environments.


Brans are always devoted to deliver satisfied and favourable services to each our clients to meet their specific needs. We deeply understand that each apllication is different and requires a customized response.To make sure
providing the best solution, the transmitter can be adapted to meet customer requirements.


Features:


• DIN35mm standard rail mounting with fixing clip

• 0.96-inch OLED display (Chinese/English selectable)

• High-speed Ethernet data transmission, strong anti-interference

• Supports MODBUS-RTU and MODBUS-TCP output

• Simultaneous use of RS232 and RS485

• Supports 4–6 x 350Ω load cells

• Maximum display range: 200,000

• Power supply: 24VDC ±1%, power ≤10W

• 4 membrane keys for operation

• Operating temperature: -10°C to 40°C; humidity: 10%–95% non-condensing

• Dimensions: 90mm×84mm×42mm; ABS flame-retardant housing; IP20 protection

Applications:

Ideal for multi-channel industrial force measurement and weighing applications requiring up to 6 independent ADC channels, resistive strain gauge sensors, and high-speed Ethernet data transmission with good noise immunity.


Specifications:
